Jual Inverter Toshiba VF-PS1

Inverter Toshiba VF-PS1 Description

Broadly applicable.

Dedicated functions for fan and pump.

Bumpless transfer: switches operation smoothly between Local Mode and Remote Mode. Fire control mode: forcibly makes the motor keep operating at the preset speed in an emergency condition. Sleep mode: automatically stops operating at lower operating condition than the minimum limit.

Improvement of energy saving effects.

The VF-PS1 has the advanced energy-saving mode, which maximizes efficiency of the motors and increases fan and pump efficiency even at low speed. *The efficiency of induction motors is normally down at low speed.

Simple set-up with Easy Key.

The Easy Key provides quick access to up to 32 frequently-used parameters (Easy Mode).

High frequency noise reduction, harmonic reduction.

The built-in EMC filters and DC reactors reduct drastically high-frequency noise and harmonics, and improve power factor

Filter for Noise Reduction

• 200 V at 0.4 to 7.5 kW: Built-in EMC filter
• 200 V at 11 kW and above: Optional.
• 400 V All models: Built-in EMC filter.

*The EMC filter complies with the European EMC Directive.

Reactor for Harmonic Reduction

• 200 V at 11 to 45 kW: Built-in DC reactor.
• 400 V at 18.5 to 75 kW: Built-in DC reactor.
• Other range: Optional

*The DC reactror meets IEC harmonic standards.

Communications

• Standard: RS485 (Modbus^®RTU / TOSHIBA) Two-Wire / Four-Wire
• Optional: CC-Link^®, DeviceNet^TM, PROFIBUS^®, LONWORKS^®, BACnet^®, Metasys^®N2, APOGEE^®FLN

Certifications

• CE, UL, CSA, SEMI F47

Applications (Motor Types: Induction motors)

• Fans and Pumps.
