Servo Panasonic Minas MHMA052P1C
Kami menjual Servo Panasonic Minas MHMA052P1C berkualitas Original dan dijamin keasliannya. Panasonic adalah merk dagang terkemuka yang telah dipakai hampir di semua pabrik yang ada di Indonesia. Kami siap memenuhi kebutuhan Servo & Drive Panasonic untuk Anda dengan cepat dengan harga bersaing di seluruh Indonesia.
High performance, multi-functional and compact AC Servo Motors from Panasonic. Panasonic Seri Servo Minas MAMA adalah Ultra Low Intertia line up dari Servo Panasonic A4 Family dengan berbagai macam fitur.
Panasonic Minas MHMA052P1C Description
| Part Number | MHMA052P1C |
| Product | MINAS A4 Family Servo motor |
| Details | High inertia, Connector type, IP65 |
| FAQ | Common item for A4 Series/AIII Series.
2D/3D data can be downloaded by selecting the CAD data file format from the external site below. |
Panasonic Minas MHMA052P1C Spec Detail
| Item | Specifications |
|---|---|
| Part Number | MHMA052P1C |
| Details | High inertia, Connector type, IP65 |
| Family Name | MINAS A4 Family |
| Series | MHMA Series |
| Type | High inertia |
| Protection class | IP65 |
| About Enclosure | Except rotating portion of output shaft and connecting pin part of the motor connector and the encoder connector. |
| Environmental Conditions | For more details, please refer to the instruction manual. |
| Flange sq. dimension | 130 mm sq. |
| Flange sq. dimension (Unit:mm) | 130 |
| Motor lead-out configuration | Connector |
| Motor encoder connector | Connector |
| Voltage specifications | 200 V |
| Rated output | 500 W |
| Holding brake | without |
| Mass (kg) | 5.3 |
| Oil seal | with |
| Shaft | Round |
| Rated torque (N ⋅ m) | 2.38 |
| Momentary Max. peak torque (N ⋅ m) | 6 |
| Max. current (A (o-p)) | 11.5 |
| Regenerative brake frequency (times/min) | Without option :No limit With option : No limit Option (External regenerative resistor) Part No. : DV0P4283 |
| Rated rotational speed (r/min) | 2000 |
| Rated rotational Max. speed (r/min) | 3000 |
| Moment of inertia of rotor ( x10-4 kg ⋅ m²) | 14.0 |
| Recommended moment of inertia ratio of the load and the rotor | 5times or less |
| Rotary encoder: specifications | 2500 P/r Incremental system |
| Remark | 1. About Regenerative brake frequency the frequency of the motor\’s stops from the rated speed with deceleration without load. . If the load is connected, frequency will be defines as 1/(m+1), where m=load moment of inertia/rotor moment of inertia. ・ When the motor speed exceeds the rated speed, regenerative brake frequency is in inverse proportion to the square of (running speed/rated speed). ・Power supply voltage is AC115 V（at 100 V of the main voltage）、AC230 V（at 200 V of the main voltage). If the supply voltage fluctuates, frequency is in inverse proportion to the square of (Running supply voltage) relative to the value in the table. ・When regeneration occurs continuously such cases as running speed frequently changes or vertical feeding, consult us or a dealer. 2. About unlimited regenerative brake frequency If the effective torque is within the rated torque, there is no limit in generative brake. 3. About recommended moment of inertia ratio of the load and the rotor Consult us or a dealer if the load moment of inertia exceeds the specified value. For details, check the catalog and instruction manuals. |
Permissible load
| Item | Specifications |
|---|---|
| During assembly: Radial load P-direction (N) | 980 |
| During assembly: Thrust load A-direction (N) | 588 |
| During assembly: Thrust load B-direction (N) | 686 |
| During operation: Radial load P-direction (N) | 490 |
| During operation: Thrust load A, B-direction (N) | 196 |
Minas A4 MHMA Part Number
| MHMA052P1C | MHMA152S1D | MHMA402P1G |
| MHMA052P1D | MHMA152S1G | MHMA402P1H |
| MHMA052P1G | MHMA152S1H | MHMA402S1C |
| MHMA052P1H | MHMA202P1C | MHMA402S1D |
| MHMA052S1C | MHMA202P1D | MHMA402S1G |
| MHMA052S1D | MHMA202P1G | MHMA402S1H |
| MHMA052S1G | MHMA202P1H | MHMA502P1C |
| MHMA052S1H | MHMA202S1C | MHMA502P1D |
| MHMA102P1C | MHMA202S1D | MHMA502P1G |
| MHMA102P1D | MHMA202S1G | MHMA502P1H |
| MHMA102P1G | MHMA202S1H | MHMA502S1C |
| MHMA102P1H | MHMA302P1C | MHMA502S1D |
| MHMA102S1C | MHMA302P1D | MHMA502S1G |
| MHMA102S1D | MHMA302P1G | MHMA502S1H |
| MHMA102S1G | MHMA302P1H | MHMA752P1C |
| MHMA102S1H | MHMA302S1C | MHMA752P1D |
| MHMA152P1C | MHMA302S1D | MHMA752P1G |
| MHMA152P1D | MHMA302S1G | MHMA752P1H |
| MHMA152P1G | MHMA302S
1H |
MHMA752S1C |
| MHMA152P1H | MHMA402P1C | MHMA752S1D |
| MHMA152S1C | MHMA402P1D | MHMA752S1G |
| MHMA752S1H |
Panasonic AC SERVOS & MOTORS
Pesan sekarang untuk cepat memenuhi kebutuhan Servo & Drive panasonic di perusahaan anda. Kami Distributor Servo & Drive Panasonic dan banyak Servo & Drive Lainnya. Untuk informasi lebih lanjut silahkan hubungi Sales Marketing kami.
