Yaskawa Rotary SGM7A
Kami menjual Yaskawa Rotary SGM7A berkualitas Original dan dijamin keasliannya. Yaskawa adalah merk dagang terkemuka yang telah dipakai hampir di semua pabrik yang ada di Indonesia. Kami siap memenuhi kebutuhan Servo & Drive Yaskawa untuk Anda dengan cepat dengan harga bersaing di seluruh Indonesia.
Rotary Servo Motors
In terms of compact size, high resolution and precise performance, the automation industry has never seen a line of rotary servo motors like today’s Sigma-7. The full range of products from 3w to 55kw perform in higher temperature extremes, at higher altitudes and in more washdown environments than ever before. Every Sigma-7 model is backward compatible with existing Sigma-5 and Sigma II products.
50W – 7kW, Low Inertia
The general-purpose workhorse of the Sigma-7 line, SGM7A is available in a wide range of sizes and covers the capacity spectrum from low to medium power. Each of these brushless rotary servo motors is capable of producing a high rate of power at extremely low levels of inertia. SGM7A servos are also designed to deliver high torque performance when an application requires it. 24-bit encoder resolution maintains industry-leading positional accuracy across the power spectrum
Features Highlights:
- 24-bit encoder resolution for superior accuracy
- More compact than other motors with similar ratings, for a better fit in tight spaces
- Completely compatible with Sigma-7 servos
- Neodymium iron boron permanent magnets with a high flux density reduce rotor size
- Advanced magnetic circuitry and optimum winding geometry deliver very low cogging torque
- Safety rated at SIL 3 (IEC 61508)
- IP67 rated for resistance to dust, water washdown
- Functions in temperatures above 60oC, altitudes above 2000 ft.
- Runs 20% cooler than previous generation products
- Holding Brake and Shaft Seal options available
Yaskawa Rotary SGM7A Models & Ratings
200V Input (24-bit encoder)
Part Number | Rated Output | Options |
|---|---|---|
| SGM7A-A5A7D61 | 50W | No Options |
| SGM7A-A5A7D6C | 50W | 24V Brake |
| SGM7A-A5A7D6E | 50W | 24V Brake, Shaft Seal |
| SGM7A-A5A7D6S | 50W | Shaft Seal |
| SGM7A-01A7D61 | 100W | No Options |
| SGM7A-01A7D6C | 100W | 24V Brake |
| SGM7A-01A7D6E | 100W | 24V Brake, Shaft Seal |
| SGM7A-01A7D6S | 100W | Shaft Seal |
| SGM7A-C2A7D61 | 150W | No Options |
| SGM7A-C2A7D6C | 150W | 24V Brake |
| SGM7A-C2A7D6E | 150W | 24V Brake, Shaft Seal |
| SGM7A-C2A7D6S | 150W | Shaft Seal |
| SGM7A-02A7D61 | 200W | No Options |
| SGM7A-02A7D6C | 200W | 24V Brake |
| SGM7A-02A7D6E | 200W | 24V Brake, Shaft Seal |
| SGM7A-02A7D6S | 200W | Shaft Seal |
| SGM7A-04A7D61 | 400W | No Options |
| SGM7A-04A7D6C | 400W | 24V Brake |
| SGM7A-04A7D6E | 400W | 24V Brake, Shaft Seal |
| SGM7A-04A7D6S | 400W | Shaft Seal |
| SGM7A-06A7D61 | 600W | No Options |
| SGM7A-06A7D61 | 600W | 24V Brake |
| SGM7A-06A7D61 | 600W | 24V Brake, Shaft Seal |
| SGM7A-06A7D61 | 600W | Shaft Seal |
| SGM7A-08A7D61 | 750W | No Options |
| SGM7A-08A7D6C | 750W | 24V Brake |
| SGM7A-08A7D6E | 750W | 24V Brake, Shaft Seal |
| SGM7A-08A7D6S | 750W | Shaft Seal |
| SGM7A-10A7D61 | 1.0kW | No Options |
| SGM7A-10A7D6C | 1.0kW | 24V Brake |
| SGM7A-10A7D6E | 1.0kW | 24V Brake, Shaft Seal |
| SGM7A-10A7D6S | 1.0kW | Shaft Seal |
| SGM7A-15A7D61 | 1.5kW | No Options |
| SGM7A-15A7D6C | 1.5kW | 24V Brake |
| SGM7A-15A7D6E | 1.5kW | 24V Brake, Shaft Seal |
| SGM7A-15A7D6S | 1.5kW | Shaft Seal |
| SGM7A-20A7D61 | 2.0kW | No Options |
| SGM7A-20A7D6C | 2.0kW | 24V Brake |
| SGM7A-20A7D6E | 2.0kW | 24V Brake, Shaft Seal |
| SGM7A-20A7D6S | 2.0kW | Shaft Seal |
| SGM7A-25A7D61 | 2.5kW | No Options |
| SGM7A-25A7D6C | 2.5kW | 24V Brake |
| SGM7A-25A7D6E | 2.5kW | 24V Brake, Shaft Seal |
| SGM7A-25A7D6S | 2.5kW | Shaft Seal |
| SGM7A-30A7D61 | 3.0kW | No Options |
| SGM7A-30A7D6C | 3.0kW | 24V Brake |
| SGM7A-30A7D6E | 3.0kW | 24V Brake, Shaft Seal |
| SGM7A-30A7D6S | 3.0kW | Shaft Seal |
| SGM7A-40A7D61 | 4.0kW | No Options |
| SGM7A-40A7D6C | 4.0kW | 24V Brake |
| SGM7A-40A7D6E | 4.0kW | 24V Brake, Shaft Seal |
| SGM7A-40A7D6S | 4.0kW | Shaft Seal |
| SGM7A-50A7D61 | 5.0kW | No Options |
| SGM7A-50A7D6C | 5.0kW | 24V Brake |
| SGM7A-50A7D6E | 5.0kW | 24V Brake, Shaft Seal |
| SGM7A-50A7D6S | 5.0kW | Shaft Seal |
| SGM7A-70A7D6S | 7.0kW | No Options |
400V Input (24-bit encoder)
Part Number | Rated Output | Options |
|---|---|---|
| SGM7A-02D7F61 | 200W | No Options |
| SGM7A-02D7F6C | 200W | 24V Brake |
| SGM7A-02D7F6E | 200W | 24V Brake, Shaft Seal |
| SGM7A-02D7F6S | 200W | Shaft Seal |
| SGM7A-04D7F61 | 400W | No Options |
| SGM7A-04D7F6C | 400W | 24V Brake |
| SGM7A-04D7F6E | 400W | 24V Brake, Shaft Seal |
| SGM7A-04D7F6S | 400W | Shaft Seal |
| SGM7A-08D7F61 | 750W | No Options |
| SGM7A-08D7F6C | 750W | 24V Brake |
| SGM7A-08D7F6E | 750W | 24V Brake, Shaft Seal |
| SGM7A-08D7F6S | 750W | Shaft Seal |
| SGM7A-10D7F61 | 1.0kW | No Options |
| SGM7A-10D7F6C | 1.0kW | 24V Brake |
| SGM7A-10D7F6E | 1.0kW | 24V Brake, Shaft Seal |
| SGM7A-10D7F6S | 1.0kW | Shaft Seal |
| SGM7A-15D7F61 | 1.5kW | No Options |
| SGM7A-15D7F6C | 1.5kW | 24V Brake |
| SGM7A-15D7F6E | 1.5kW | 24V Brake, Shaft Seal |
| SGM7A-15D7F6S | 1.5kW | Shaft Seal |
| SGM7A-20D7F61 | 2.0kW | No Options |
| SGM7A-20D7F6C | 2.0kW | 24V Brake |
| SGM7A-20D7F6E | 2.0kW | 24V Brake, Shaft Seal |
| SGM7A-20D7F6S | 2.0kW | Shaft Seal |
| SGM7A-25D7F61 | 2.5kW | No Options |
| SGM7A-25D7F6C | 2.5kW | 24V Brake |
| SGM7A-25D7F6E | 2.5kW | 24V Brake, Shaft Seal |
| SGM7A-25D7F6S | 2.5kW | Shaft Seal |
| SGM7A-30D7F61 | 3.0kW | No Options |
| SGM7A-30D7F6C | 3.0kW | 24V Brake |
| SGM7A-30D7F6E | 3.0kW | 24V Brake, Shaft Seal |
| SGM7A-30D7F6S | 3.0kW | Shaft Seal |
| SGM7A-40D7F61 | 4Kw | No Options |
| SGM7A-40D7F6C | 4kW | 24V Brake |
| SGM7A-40D7F6E | 4kW | 24V Brake, Shaft Seal |
| SGM7A-40D7F6S | 4kW | Shaft Seal |
| SGM7A-50D7F61 | 5kW | No Options |
| SGM7A-50D7F6C | 5kW | 24V Brake |
| SGM7A-50D7F6E | 5kW | 24V Brake, Shaft Seal |
| SGM7A-50D7F6S | 5kW | Shaft Seal |
Product Yaskawa Gear Motors:
- S7J Gear Motors 100W – 750W (200V), 200W – 1.5kW (400V)
- S7A Gear Motors 100W – 7kW (200V), 200W – 1kW (400V)
- S7P Gear Motors 100W – 1.5kW (200V)
- S7G Gear Motors 500W – 7.5kW (200V)
