Yaskawa Rotary SGM7G
Kami menjual Yaskawa Rotary SGM7G berkualitas Original dan dijamin keasliannya. Yaskawa adalah merk dagang terkemuka yang telah dipakai hampir di semua pabrik yang ada di Indonesia. Kami siap memenuhi kebutuhan Servo & Drive Yaskawa untuk Anda dengan cepat dengan harga bersaing di seluruh Indonesia.
Rotary Servo Motors
In terms of compact size, high resolution and precise performance, the automation industry has never seen a line of rotary servo motors like today’s Sigma-7. The full range of products from 3w to 55kw perform in higher temperature extremes, at higher altitudes and in more washdown environments than ever before. Every Sigma-7 model is backward compatible with existing Sigma-5 and Sigma II products.
300W – 15kW, Medium Inertia
The increased power demands of large automation components utilize the robust performance of SGM7G. These servo motors are built with a compact footprint, yet provide a higher torque while maintaining an inertia rating well within the medium range. Rated torques in the SGM7G family range up to 95.2 N-m (840 in-lb). SGM7G delivers a rated speed of 1500 rpm, delivering a rapid and consistent throughput over a wide power range. 24-bit encoder resolution maintains industry-leading positional accuracy across the power spectrum.
Features Highlights:
- 24-bit encoder resolution
- More compact in size than most motors in its class
- Completely compatible with Sigma-7 servos
- Neodymium iron boron permanent magnets with a high flux density reduce rotor size
- Advanced magnetic circuitry and optimum winding geometry deliver very low cogging torque
- Safety rated at SIL 3 (IEC 61508)
- IP67 rated for resistance to dust, water washdown
- Peak acceleration torque up to 300% of rated torque
- Peak torque can be maintained for up to three seconds
- Rated speed of 1500 rpm, max speed of 3000 rpm
- Functions in temperatures above 60oC, altitudes above 2000 ft.
- Runs 20% cooler than previous generation products
- Holding Brake and Shaft Seal options available
Yaskawa Rotary SGM7G Models & Ratings
200V Input (24-bit encoder)
|
Part Number
|
Rated Output
|
Options
|
|---|---|---|
| SGM7G-03A7DK1 | 300W | No Options |
| SGM7G-03A7DKC | 300W | 24V Brake |
| SGM7G-03A7DKE | 300W | 24V Brake, Shaft Seal |
| SGM7G-03A7DKS | 300W | Shaft Seal |
| SGM7G-05A7D61 | 450W | No Options |
| SGM7G-05A7D6C | 450W | 24V Brake |
| SGM7G-05A7D6E | 450W | 24V Brake, Shaft Seal |
| SGM7G-05A7D6S | 450W | Shaft Seal |
| SGM7G-09A7DK1 | 850W | No Options |
| SGM7G-09A7DKC | 850W | 24V Brake |
| SGM7G-09A7DKE | 850W | 24V Brake, Shaft Seal |
| SGM7G-09A7DKS | 850W | Shaft Seal |
| SGM7G-13A7DK1 | 1.3kW | No Options |
| SGM7G-13A7DKC | 1.3kW | 24V Brake |
| SGM7G-13A7DKE | 1.3kW | 24V Brake, Shaft Seal |
| SGM7G-13A7DKS | 1.3kW | Shaft Seal |
| SGM7G-20A7D61 | 2kW | No Options |
| SGM7G-20A7D6C | 2kW | 24V Brake |
| SGM7G-20A7D6E | 2kW | 24V Brake, Shaft Seal |
| SGM7G-20A7D6S | 2kW | Shaft Seal |
| SGM7G-30A7D61 | 3kW | No Options |
| SGM7G-30A7D6C | 3kW | 24V Brake |
| SGM7G-30A7D6E | 3kW | 24V Brake, Shaft Seal |
| SGM7G-30A7D6S | 3kW | Shaft Seal |
| SGM7G-44A7D61 | 4.4kW | No Options |
| SGM7G-44A7D6C | 4.4kW | 24V Brake |
| SGM7G-44A7D6E | 4.4kW | 24V Brake, Shaft Seal |
| SGM7G-44A7D6S | 4.4kW | Shaft Seal |
| SGM7G-55A7D61 | 5.5kW | No Options |
| SGM7G-55A7D6C | 5.5kW | 24V Brake |
| SGM7G-55A7D6E | 5.5kW | 24V Brake, Shaft Seal |
| SGM7G-55A7D6S | 5.5kW | Shaft Seal |
| SGM7G-75A7D61 | 7.5kW | No Options |
| SGM7G-75A7D6C | 7.5kW | 24V Brake |
| SGM7G-75A7D6E | 7.5kW | 24V Brake, Shaft Seal |
| SGM7G-75A7D6S | 7.5kW | Shaft Seal |
| SGM7G-1AA7D61 | 11kW | No Options |
| SGM7G-1AA7D6C | 11kW | 24V Brake |
| SGM7G-1AA7D6E | 11kW | 24V Brake, Shaft Seal |
| SGM7G-1AA7D6S | 11kW | Shaft Seal |
| SGM7G-1EA7D61 | 15kW | No Options |
| SGM7G-1EA7D6C | 15kW | 24V Brake |
| SGM7G-1EA7D6E | 15kW | 24V Brake, Shaft Seal |
| SGM7G-1EA7D6S | 15kW | Shaft Seal |
400V Input (24-bit encoder)
|
Rated Output
|
Options
|
|
|---|---|---|
| SGM7G-05D7F61 | 450W | No Options |
| SGM7G-05D7F6C | 450W | 24V Brake |
| SGM7G-05D7F6E | 450W | 24V Brake, Shaft Seal |
| SGM7G-05D7F6S | 450W | Shaft Seal |
| SGM7G-09D7FK1 | 850W | No Options |
| SGM7G-09D7FKC | 850W | 24V Brake |
| SGM7G-09D7FKE | 850W | 24V Brake, Shaft Seal |
| SGM7G-09D7FKS | 850W | Shaft Seal |
| SGM7G-13D7FK1 | 1.3kW | No Options |
| SGM7G-13D7FKC | 1.3kW | 24V Brake |
| SGM7G-13D7FKE | 1.3kW | 24V Brake, Shaft Seal |
| SGM7G-13D7FKS | 1.3kW | Shaft Seal |
| SGM7G-20D7F61 | 2.0kW | No Options |
| SGM7G-20D7F6C | 2.0kW | 24V Brake |
| SGM7G-20D7F6E | 2.0kW | 24V Brake, Shaft Seal |
| SGM7G-20D7F6S | 2.0kW | Shaft Seal |
| SGM7G-30D7F61 | 3.0kW | No Options |
| SGM7G-30D7F6C | 3.0kW | 24V Brake |
| SGM7G-30D7F6E | 3.0kW | 24V Brake, Shaft Seal |
| SGM7G-30D7F6S | 3.0kW | Shaft Seal |
| SGM7G-44D7F61 | 4.4kW | No Options |
| SGM7G-44D7F6C | 4.4kW | 24V Brake |
| SGM7G-44D7F6E | 4.4kW | 24V Brake, Shaft Seal |
| SGM7G-44D7F6S | 4.4kW | Shaft Seal |
| SGM7G-55D7F61 | 5.5kW | No Options |
| SGM7G-55D7F6C | 5.5kW | 24V Brake |
| SGM7G-55D7F6E | 5.5kW | 24V Brake, Shaft Seal |
| SGM7G-55D7F6S | 5.5kW | Shaft Seal |
| SGM7G-75D7F61 | 7.5kW | No Options |
| SGM7G-75D7F6C | 7.5kW | 24V Brake |
| SGM7G-75D7F6E | 7.5kW | 24V Brake, Shaft Seal |
| SGM7G-75D7F6S | 7.5kW | Shaft Seal |
| SGM7G-1AD7F61 | 11kW | No Options |
| SGM7G-1AD7F6C | 11kW | 24V Brake |
| SGM7G-1AD7F6E | 11kW | 24V Brake, Shaft Seal |
| SGM7G-1AD7F6S | 11kW | Shaft Seal |
| SGM7G-1ED7F61 | 15kW | No Options |
| SGM7G-1ED7F6C | 15kW | 24V Brake |
| SGM7G-1ED7F6E | 15kW | 24V Brake, Shaft Seal |
| SGM7G-1ED7F6S | 15kW | Shaft Seal |
