Yaskawa SGD7S 7Siec
Kami menjual Yaskawa SGD7S 7Siec berkualitas Original dan dijamin keasliannya. Yaskawa adalah merk dagang terkemuka yang telah dipakai hampir di semua pabrik yang ada di Indonesia. Kami siap memenuhi kebutuhan Servo & Drive Yaskawa untuk Anda dengan cepat dengan harga bersaing di seluruh Indonesia.
Compact, cost-saving single axis controller/amplifier
Put complete control for a single axis of servo motion in one compact unit that conserves space in control cabinets. Sigma-7 Siec combines a Sigma-7 SERVOPACK amplifier and one axis of machine control in the space of a conventional amplifier, at a significant savings when compared to a pair of separate components.
Features Single Axis Controller Features
- Compact package
- IEC61131-3 and PLCopen programming standard
- Controller and SERVOPACK integrated in one compact unit
- Single axis of motion control
- Open standards EtherNet/IP and Modbus TCP for connectivity to nearly every PLC, HMI and remote I/O (Including our very own VIPA SLIO I/O) on the market
- Built-in web server with standard controller diagnostic features
Note: The Sigma-7Siec does not have internal battery backed RAM
SERVOPACK Features
- Industry-leading 3.1kHz bandwidth significantly improves settling time.
- Tuning-less capability reliably tunes servo system automatically – no user adjustment needed.
- Powerful package of tuning functions include compensation for the effects of machine inertia, vibration, friction, and ripples in output.
- Maintains tuning accuracy despite inertia changes up to 30:1.
- IEC 61508 SIL3 safety certification.
- Completely compatible with Sigma-5 servo motors.
- Improved filtering minimizes inaccuracies due to electrical interference, machine resonance and mechanical vibration.
Models & Ratings
100V Input
|
Part Number
|
Rated Output
|
|---|---|
| SGD7S-R70FM0A000F50 | 50W |
| SGD7S-R90FM0A000F50 | 100W |
| SGD7S-2R1FM0A000F50 | 200W |
| SGD7S-2R8FM0A000F50 | 400W |
200V Input
|
Part Number
|
Rated Output
|
|---|---|
| SGD7S-R70AM0A000F50 | 50W |
| SGD7S-R90AM0A000F50 | 100W |
| SGD7S-1R6AM0A000F50 | 200W |
| SGD7S-2R8AM0A000F50 | 400W |
| SGD7S-3R8AM0A000F50 | 500W |
| SGD7S-5R5AM0A000F50 | 750W |
| SGD7S-7R6AM0A000F50 | 1.0kW |
| SGD7S-120AM0A000F50 | 1.5kW |
| SGD7S-180AM0A000F50 | 2.0kW |
| SGD7S-200AM0A000F50 | 3.0kW |
| SGD7S-330AM0A000F50 | 5.0kW |
| SGD7S-470AM0A000F50 | 6.0kW |
| SGD7S-550AM0A000F50 | 7.5kW |
| SGD7S-590AM0A000F50 | 11kW |
| SGD7S-780AM0A000F50 | 15kW |
200V Input with FT82 Option (Support SGM7D Motors)
|
Part Number
|
Rated Output
|
|---|---|
| SGD7S-R70AM0A000F82 | 50W |
| SGD7S-R90AM0A000F82 | 100W |
| SGD7S-1R6AM0A000F82 | 200W |
| SGD7S-2R8AM0A000F82 | 400W |
| SGD7S-3R8AM0A000F82 | 500W |
| SGD7S-5R5AM0A000F82 | 750W |
| SGD7S-7R6AM0A000F82 | 1.0kW |
| SGD7S-120AM0A000F82 | 1.5kW |
| SGD7S-180AM0A000F82 | 2.0kW |
| SGD7S-200AM0A000F82 | 3.0kW |
| SGD7S-330AM0A000F50 | 5.0kW |
| SGD7S-470AM0A000F82 | 6.0kW |
| SGD7S-550AM0A000F82 | 7.5kW |
| SGD7S-590AM0A000F82 | 11kW |
| SGD7S-780AM0A000F82 | 15kW |
400V Input
|
Rated Output
|
|
|---|---|
| SGD7S-1R9DM0B000F50 | 500W |
| SGD7S-3R5DM0B000F50 | 1.0kW |
| SGD7S-5R4DM0B000F50 | 1.5kW |
| SGD7S-8R4DM0B000F50 | 2.0kW |
| SGD7S-120DM0B000F50 | 3.0kW |
| SGD7S-170DM0B000F50 | 5.0kW |
| SGD7S-210DM0B000F50 | 6.0kW |
| SGD7S-260DM0B000F50 | 7.5kW |
| SGD7S-280DM0B000F50 | 11kW |
| SGD7S-370DM0B000F50 | 15kW |
