Yaskawa SGDV SigmaLogic Sigma-V

Kami menjual Yaskawa SGDV SigmaLogic Sigma-V berkualitas Original dan dijamin keasliannya. Yaskawa adalah merk dagang terkemuka yang telah dipakai hampir di semua pabrik yang ada di Indonesia. Kami siap memenuhi kebutuhan Servo & Drive Yaskawa untuk Anda dengan cepat dengan harga bersaing di seluruh Indonesia.

SGDV SigmaLogic

The SGDV SigmaLogic is a SERVOPACK with included Add On Instructions (AOIs) for the Rockwell ControlLogix and CompactLogix PLCs, no other programming software is required.

Yaskawa SGDV SigmaLogic Sigma-V Features Highlights

The SigmaLogic allows Sigma 5 amplifier motion sequencing and axis control using Rockwell ControlLogix and CompactLogix PLCs via Add On Instructions (AOIs).

Highlights

  • No other progamming software needed
  • Use direct command or 200 point configurable sequence table
  • Contains all the benefits of the Sigma-5 Servo System

Add-On Instructions

  • Compatible with all CompactLogix and ControlLogix PLCs using RSLogix5000 software v17 and above
  • Familiar to AB users
  • Sample Program in RSLogix5000 available

Sequence Table

    • Create individual move profiles and sequencing for the application with the free LogicWorks utility
    • Download/Upload sequence table and configuration data to or from LogicWorks
    • Embedded monitoring and test functions

Specifications

ItemSpecification
SoftwareSigmaSelect
SigmaWin+ Ver.5
SigmaLogic Software Package
CPU200 MHz, 32 bit, ARM
MemorySDRAM, 32 MB
SRAM, 512 kB with battery backup
Flash, 4 MB flash. Code and parameter storage
Operator interfaceLED:
10 LEDs (red and green – operating mode, communication and error status)
User Configuration:
6x DIP switch (operating mode and communication configuration)
Environmental ConditionsAmbient Operating Temperature:
0°C to 55°CAmbient Storage Temperature:
-20° to 85°CAmbient Operating Humidity:
90% RH or less (with no condensation)Ambient Storage Humidity:
90% RH or less (with no condensation)

Pollution Level:
Protection class: IP10, Pollutio degree:2

  • Free of corrosive or explosive gases
  • Free of exposure to water, oil, or chemicals
  • Free of dust, salts or iron dust

Operating Altitude:
1,000 m above sea level or lower

Mechanical Operating ConditionsVibration Resistance:
4.9 m/s2Shock Resistance:
19.6 m/s2Others:
Free of static electricity, strong electromagnetic fields, magnetics fields or exposure to radioactivity
Servo-Side Safety FunctionsInput:
/HWBB1, /HWBB2: Baseblock signal for power module
Output:
EDM1: Status monitor (fixed output) of built-in safety circuit
Network CapabilitiyEtherNet/IP
Diagnostic and configuration interfaceWeb interface
Motion control performance1 controlled axis and one external position input at a trajectory update rate of 1 kHz

Yaskawa SGDV SigmaLogic Sigma-V Models & Ratings

Single-phase 100 V

SERVOPACK Model SGDV-
R70F
R90F
2R1F
2R8F
Applicable Servomotor Max. Capacity kW
0.05
0.1
0.2
0.4
Continuous Output Current Arms
0.66
0.91
2.1
2.8
Max. Output Current Arms
2.1
2.9
6.5
9.3
Main Circuit (Single Phase)100 to 115 VAC+10% to −15% 50/60 Hz
Control Circuit (Single Phase)100 to 115 VAC+10% to −15% 50/60 Hz

Single-phase 200 V

SERVOPACK Model SGDV-120
Applicable Servomotor Max. Capacity kW1.5
Continuous Output Current Arms11.6
Max. Output Current Arms28
Main Circuit (Single Phase)220 to 230 VAC+10% to −15% 50/60 Hz
Control Circuit (Single Phase)220 to 230 VAC+10% to −15% 50/60 Hz

Three-phase 200 V

SERVOPACK Model SGDV-
R70A
R90A
1R6A
2R8A
3R8A
5R5A
7R6A
120A
Applicable Servomotor Max. Capacity kW
0.05
0.1
0.2
0.4
0.5
0.75
1.0
1.5
Continuous Output Current Arms
0.66
0.91
1.6
2.8
3.8
5.5
7.6
11.6
Max. Output Current Arms
2.1
2.9
6.5
9.3
11
16.9
17
28
Main CircuitThree-phase 200 to 230 VAC+10% to −15% 50/60 Hz
Control CircuitSingle-phase 200 to 230 VAC+10% to −15% 50/60 Hz
SERVOPACK Model SGDV-
180A
200A
330A
470A
550A
590A
780A
Applicable Servomotor Max. Capacity kW
2.0
3.0
5.0
6
7.5
11
15
Continuous Output Current Arms
18.5
19.6
32.9
46.9
54.7
58.6
78
Max. Output Current Arms
42
56
84
110
130
140
170
Main CircuitThree-phase 200 to 230 VAC+10% to −15% 50/60 Hz
Control CircuitSingle-phase 200 to 230 VAC+10% to −15% 50/60 Hz

Three-phase 400 V

SERVOPACK Model SGDV-1R9D3R5D5R4D8R4D120D170D210D260D280D370D
Applicable Servomotor Max. Capacity kW0.51.01.52.03.05.067.51115
Continuous Output Current Arms1.93.55.48.411.916.520.825.428.137.2
Max. Output Current Arms5.58.51420284255657085
Main CircuitThree-phase 380 to 480 VAC+10% to −15% 50/60 Hz
Control Circuit24 VDC ±15%
