Kami menjual Produk YOKOGAWA UT35A/UT32A Yang Berkualitas Original Dengan harga yang bersaing Kebutuhan anda Kami Solusinya
The UT35A and UT32A temperature controllers employ an easy-to-read, 14-segment large color LCD display, along with navigation keys, thus greatly increasing the monitoring and operating capabilities. A ladder sequence function is included as standard. The short depth of the controller helps save instrument panel space. The UT35A/UT32A also support open networks such as Ethernet communication.
UT35A and UT32A Temperature Controller Features
- 4 target setpoints (PID numbers) available as standard
- 3 alarm independent common terminals available as standard
- Ladder sequence programs can be built
- Simple operation
- Up to 8 DOs (combinations available)
- Multiple language operation manual (Japanese, English, German, French, Spanish, Chinese and Korean) available. Please specify the desired language when ordering.
- Detailed code model available to customize specifications best suited to you.
Specifications YOKOGAWA UT35A/UT32A
| ITEM | UT35A | UT32A | |
|---|---|---|---|
| PV input | Input type | 1 Universal input (TC, RTD, mV, V, mA) | |
| Indication accuracy | ±0.1% of F.S. | ||
| Control scan period | 200 msec | ||
| PV/SP data display | 14-segment, 5 digits, Bar graph LCD display | ||
| Control outputs (MV) | Type | Relay, Voltage Pulse, Current | |
| Algorithm | ON/OFF, PID (Continuous, Time-proportional), Heating/Cooling, Position-proportional | ||
| Digital inputs | Number | 2 (Std) 7 (Max) | 2 (Std) 4 (Max) |
| Type | SP No.Change, PID No. Change, A/M Change, etc | ||
| Digital outputs | Number | 3 (Std) 8 (Max) | 3 (Std) 5 (Max) |
| Function | PV High, PV Low, Dev High, etc | ||
| Current trans input (option） | Number | 2 | |
| Retransmission | Number | 1 | |
| Type | PV, SP, OUT, etc | ||
| Remote (aux.) input (option) | Number | – | – |
| Type | – | ||
| Loop power supply (LPS) (option) | Number | 1 | |
| Voltage | 21.6 to 28.0 VDC | ||
| Communication (option) | Number | 1 | 1 |
| Type | RS-485, Ethernet, PROFIBUS-DP, CC-Link, DeviceNet | RS-485, CC-Link | |
| Other specifications | Power supply | 100 to 240 VAC (+10%, -15%) or 24 VAC/DC (+10%, -15%) (option) | |
| Power consumption | Max 18 VA | Max 15 VA | |
| Mass | Max 0.5 kg |
Pesan sekarang untuk cepat memenuhi kebutuhan Sensor YOKOGAWA di perusahaan anda. Kami Distributor Sensor & Controler YOKOGAWA dan banyak Sensor & Controler Lainnya. Untuk informasi lebih lanjut silahkan hubungi Sales Marketing kami.
