Inverter Micno KE300M
Kami Jual Inverter Micno KE300M berkualitas Original dan dijamin keasliannya. Micno adalah merk dagang terkemuka yang telah dipakai hampir di semua pabrik yang ada di Indonesia. Kami siap memenuhi kebutuhan inverter Micno untuk Anda dengan cepat dengan harga bersaing di seluruh Indonesia.
Inverter Micno KE300M Series IF Power Inverter
KE300M series intermediate frequency power supply is a device that converts three-phase current into an intermediate frequency current . It is a static frequency conversion device that uses the principle of electromagnetic induction eddy current loss to heat the workpiece. It transforms the three-phase power frequency power supply into a single-phase power output. It has strong adaptability to various loads and a wide range of applications
Specifications of KE300M Series IF Power Inverter
| Function description | Specifications | |
| Power input | Input voltage（V） | AC 3PH 380V(-15%)~440V(+10%) default 380V |
| Input frequency（Hz） | 50Hz or 60Hz Allowable range 47~63Hz | |
| Power output | Output voltage（V） | Square wave 1PH 0~540V |
| Output frequency（Hz） | 50~6000Hz | |
| Special function | Resonant frequency automatically | Automatically detect and adjust the output frequency according to the load. The output reaches the best state which improves equipment efficiency and reduces manual debugging time. |
| Short-term overcurrent warning and overcurrent shutdown function | The overload warning current size and warning time can be set, and the default overcurrent point of the intermediate frequency power supply is too large | |
| Temperature control function | Set the lower and upper temperature limit, the system automatically runs within the temperature setting range. | |
| Others | Installation method | wall-mounted, floor-mounted, and flange-mounted. |
| Operating ambient temperature | -10~50℃，derated when the temperature up to 40℃ | |
| Protection level | IP20 | |
| cooling method | Forced air cooling | |
| EMC filter | Optional C3 filter: meet IEC61800-3 C3 level requirements
Optional external filter: meet IEC61800-3 C2 level requirements |
Selection Table
| Inverter model | Variable torque | ||
| Output power rating
(kW) |
Input amperage
(A) |
Output amperage
(A) |
|
| KE300M-2.2KW-09A-T4 | 2.2 | 12.5 | 9.0 |
| KE300M-4KW-013A-T4 | 4 | 18.5 | 13 |
| KE300M-5.5KW-017A-T4 | 5.5 | 24 | 17 |
| KE300M-7.5KW-025A-T4 | 7.5 | 32 | 25 |
| KE300M-11KW-032A-T4 | 11 | 40 | 32 |
| KE300M-15KW-037A-T4 | 15 | 47 | 37 |
| KE300M-18.5KW-045A-T4 | 18.5 | 56 | 45 |
| KE300M-22KW-060A-T4 | 22 | 70 | 60 |
| KE300M-30KW-075A-T4 | 30 | 80 | 75 |
| KE300M-37KW-090A-T4 | 37 | 94 | 92 |
| KE300M-45KW-110A-T4 | 45 | 125 | 110 |
| KE300M-55KW-150A-T4 | 55 | 160 | 150 |
| KE300M-75KW-150A-T4 | 75 | 185 | 176 |
| KE300M-90KW-210A-T4 | 90 | 220 | 210 |
| KE300M-110KW-253A-T4 | 110 | 265 | 253 |
| KE300M-132KW-304A-T4 | 132 | 310 | 304 |
| KE300M-160KW-340A-T4 | 160 | 345 | 340 |
| KE300M-185KW-377A-T4 | 185 | 385 | 377 |
| KE300M-200KW-423A-T4 | 200 | 430 | 423 |
| KE300M-220KW-465A-T4 | 220 | 480 | 465 |
| KE300M-250KW-520A-T4 | 250 | 545 | 520 |
| KE300M-280KW-585A-T4 | 280 | 610 | 585 |
| KE300M-315KW-640A-T4 | 315 | 625 | 640 |
| KE300M-350KW-720A-T4 | 350 | 715 | 720 |
| KE300M-400KW-720A-T4 | 400 | 880 | 820 |
| KE300M-500KW-1000A-T4 | 500 | 1090 | 1000 |
| KE300M-560KW-1100A-T4 | 560 | 1170 | 1100 |
| KE300M-630KW-1250A-T4 | 630 | 1330 | 1250 |
| KE300M-710KW-1400A-T4 | 710 | 1490 | 1400 |
MICNO industrial AC speed drives adopt world-class vector control technology and they can be equipped with rich function expansion cards, flexible application, stable operation
